1. Introduction
There have been many natural large-scale disasters, such as big earthquakes (e.g., the 3.11 Great East Japan Earthquake that almost shook the whole country), massive flooding and landslides caused by heavy rains, and man-made fire disasters (large-scale fires) in Japan. All these disasters require an immediate response by the disaster response team; usually the fire fighters are at the forefront in search and rescue operations. Fire fighters are required to promptly carry out diverse life-saving and firefighting activities as fast as possible and within 72 h of the disaster, a time which is critical to save lives under the harsh environment. To do so effectively, fire fighters energy levels are an important aspect to be considered and therein are the topic of the current research—‘energy expenditure’ of fire fighters. Although the energy expenditure of firefighting and rescue operations has been partially investigated, such as ladder climbing and lowering and firefighting activities [
1,
2], to the best of our knowledge, no studies are available on estimating the energy expenditure of each type of disaster relief operations during a large-scale disaster. In addition, since fire fighters play various roles in large-scale disaster relief operations, such as rescue, firefighting, emergency medical service (EMS), and logistical support activities, the equipment and intensity of activities differ greatly depending on the type of activity undertaken [
3]. Such differences have made it difficult to achieve reliable energy expenditure estimation.
Previously, to demonstrate a standard value of energy expenditure for a given physical activity, Ainsworth et al. (2011) presented 821 activities [
4,
5,
6]. Therein, the activities of fire fighters have been described by four types: (1) general; (2) rescue victim, automobile accident, using pike pole; (3) raising and climbing a ladder with full gear, simulated fire suppression; and (4) hauling hoses on the ground, carrying/hoisting equipment, breaking down walls, etc., while wearing full gear. There are studies, such as of the rescue of rescuers with ladder lifting and lowering and fire-fighting activities involving ladder lifting and lowering by expiratory gas analysis [
1,
2]. However, since the types of firefighting and rescue activities in large-scale disaster relief operations are not limited to single movements, such as fire extinguishing and ladder raising and lowering that are performed in normal operations, but also a wide range of activities, such as rescue activities from collapse sites and rescue activities from sediment burial sites due to landslides, it is necessary to consider more types of activities.
The gold standard for estimating energy expenditure is the Doble labeled water (DLW) method, but it is difficult to estimate the energy expenditure of a particular day by estimating the average of multiple days as the total energy expenditure per day, and it is not possible to cut out the time [
7]. Exhaled gas analysis (or a douglas bag to collect expiratory gas) is another method of carrying out estimation in the laboratory, but the range of activities is restricted [
7]. As alternative method that can reduce the time and can examine each (diverse) activity type, and it does not place much restriction on the activity, and the accelerometer and heart rate methods have been considered for measuring the energy expenditure using wearable devices. As a method of measuring disaster activity, corresponding to multifaceted damage in a large-scale disaster, activities that are closer to the actual (ground situation) were considered, as they are difficult to reproduce in the laboratory condition. Therefore, the effectiveness of using a wearable device that is low in invasiveness and can be adapted out in the field to actual disaster activities by fire fighters was considered. For example, a study on physiological changes during the activities of Canadian mine rescue workers used wearable devices [
8], as well as in studies for a comparison of fire fighters’ activity during on-duty and off-duty [
9].
In recent years, wearable devices that are less invasive, small, and easy to carry have been developed, and the accuracy of these has also been discussed in comparison with the DLW method and chambers [
10,
11]. In estimating energy expenditure, each method has its own limitations. Therefore, it has been suggested that combining multiple methods enables more accurate studies [
12]. Studies have seen the use of accelerometers in surveys of physical activity of fire fighters. As a result of measuring the energy expenditure of firefighting activities using the accelerometer (AC) and heart rate (HR) methods through wearable devices, it was possible to confirm the activities that are not reflected in the numerical value by the AC method, but which are reflected in the HR method, and by combining the AC method and the HR method, underestimation could be generated in the estimation using the AC method alone [
13]. In addition, it has been reported that fire fighters were able to estimate energy expenditure using a combination of a tri-axial accelerometer and a wearable heart rate monitor [
14].
With this background, using an estimation formula combining a tri-axial accelerometer and a wearable heart rate monitor, the energy expenditure per hour for each activity type during large-scale disaster activities was estimated. The purpose of this study is to ultimately calculate it as a reference value that can be used as a standard value for each type of activity when estimating energy expenditure during future disaster activities.
3. Results
3.1. Survey Respondents
We surveyed 30 subjects (fire fighters). However, as two subjects had defects in the data (during data collection period), which was due to technical issues/equipment failure, they were excluded from the results; the data of 28 subjects () were analyzed. The survey respondents were divided into six groups of five people from each group, and they were active from 11 a.m. to the next 11 a.m. The simulation training started at 8:30 a.m., and almost all teams (research subjects therein) arrived from their base by vehicles at the training site around 11 a.m. and started the activity.
Table 1.
Characteristics of the survey respondents.
3.2. Details of the Activities each Activity Group
The METs and total energy expenditure for each activity type by activity group are shown (). METs for each type of activity ranged from 4.3 METs to 7.0 METs. The main activities of Groups 1 and 2 were gas leak rescue (). Due to the impact of the earthquake in the complex, buildings collapsed, facilities and equipment were damaged, and fires associated with this occurred. It was assumed that toxic gas leaks occurred on the third basement floor of the ventilation facility, and that there were several delays in escape. The survey respondents wore a protective suit that prevents the inhalation of toxic gases on top of their normal equipment (fire protection coat), and because they carried oxygen cylinders on their backs, they were able to operate under a load that was higher than normal equipment. Groups 3 and 4 were mainly responsible for the rescue from high-rise buildings (). As expected, several employees who were conducting evacuation guidance were injured when the ceiling collapsed when an earthquake occurred, while several tourists were touring the city on the observation floor of the 69th floor of a high-rise building. The elevator was disabled, and access to the upper floors was only by emergency stairs. Eight of the rescuers were able to walk, but five of them, including two seriously injured, were unable to walk, so the respondent descended the stairs from the upper floors with the load of the rescued person by stretcher transport or backpack rescue. It is to be noted that, in the above, there was one stairwell up and down to the 69th floor observation deck, and it was comprised of only one rescue training up and down the staircase. Groups 5 and 6 were mainly responsible for landslide disasters and tunnel collapse accidents (). The landslide occurred due to an earthquake, and one passenger car was half buried in the mudslide, and one subsequent passenger car collided. It was assumed that there were injured people inside, but that the door was out of shape by the impact of the collision and could not be opened. Some large heavy machinery was used to remove soil and sand and to open and close doors. In the case of the tunnel collapse accident, when entering the tunnel, they wore oxygen cylinders and acted with load. The lights were off in the tunnel, and they operated with the light of the headlights in the midst of poor visibility.
Figure 1.
Photos for each firefighting activity illustrate the difference in scenarios and equipment’s used. Depending on the equipment, there are differences in weight, ease of breathing, ease of movement, etc. Activities of Groups 1 and 2 corresponded to a gas leak accident at the complex. They wore protective clothing sealed over their usual equipment to avoid inhaling toxic gases and are carrying oxygen cylinders. Activities of Groups 3 and 4 involved climbing staircases where they had to go up and down the floors of a high-rise building as rescue personnel. They climbed the stairs to the upper floors with their usual equipment, and after the rescue operation, they went down the stairs while transporting people in need of rescue on stretchers and on their backs. Activities of Groups 5 and 6 show engagement in landslide disaster activities and tunnel collapse accident relief activities. In the tunnel collapse accident rescue operation, the activity was carried out with an oxygen cylinder on their back so as not to inhale the toxic gases and dust in the tunnel.
Table 2.
The average METs and activity time for each type of large-scale disaster relief operations activity.
For each group to which the participants belonged, the contents of the activities were read from the activity record sheet and categorized. The average METs value (±SD) and activity time for 1 min for each activity type are shown. Activities of Groups 1 and 2 corresponded to a gas leak accident at the complex. Activities of Groups 3 and 4 involved climbing staircases where they had to go up and down the floors of a high-rise building as rescue personnel. Fire fighters climbed the stairs to the upper floors with the equipment they normally use, and after the rescue operation, they went down the stairs while transporting people in need of rescue on stretchers and on their backs. Group 3 joined the general firefighting after skyscraper training. Activities of Groups 5 and 6 show engagement in landslide disaster activities and tunnel collapse accident relief activities. Group 5 joined the rescuer transport after the landslide disaster activities.
3.3. Energy Expenditure by Type of Activity
Based on the results obtained for the details of activities in each activity group, equivalent activities were classified by activity type as a reference data of energy expenditure per hour for 10 types of large-scale disaster relief operations (). Rescue operations from small areas consumed the least energy, estimated at 249 kcal per hour. The activity was part of a rescue operation from the collapsed building. Firefighting activity consumed 291 kcal per hour. Gas-related accidents consumed around 327 kcal per hour. The activity was heavy due to the layering of protective clothing on top of normal activity clothes and equipment, and the load had been increased because it blocked the outside air. The tunnel collapse accident consumed an estimated 355 kcal per hour. This activity is considered to be of high risk due to toxic gas accumulating in the tunnel, so fire fighters have to wear a respirator, and breathing is restricted. It also includes high-impact activities, such as the removal of debris from tunnel collapses. The use of large heavy machinery was also confirmed in these activities. Rescue operations from high altitudes showed the highest energy expenditure, estimated at 419 kcal per hour. When going up the stairs, fire fighters must run with full equipment to the site as soon as possible where the victim is located. Additionally, while coming down from a higher place, an additional load is added by the presence of a victim either on their back or on the stretcher.
Table 3.
Data corresponding to the average METs per minute for each activity type, including the reference data of energy expenditure per hour.
4. Discussion
Here, we demonstrated the practicality and effectiveness of a wearable device-based approach for the TEE estimation in large-scale disaster activities. The standard value of energy expenditure for each type of activity was determined using an estimation formula combining a tri-axial accelerometer and a wearable heart rate monitor. The activities of the fire fighters in large disaster are a complex combination of various activities. To estimate the energy expenditure of fire fighters’ activities, it is necessary to grasp the entire series of flows connected to each activity. The physical activity intensity of firefighting activity has been reported for each part (e.g., ladder climbing, dragging hoses on the ground) [
2]. To know the energy expenditure per hour, it is possible to estimate the total energy expenditure of activities in a large-scale disaster. In this study, in a long-term drill in which multiple disaster activities are performed, the energy expenditure per hour of each activity was investigated in actual activities. This result could help our understanding for the energy expenditure of fire fighters engaged in complex disaster activities. The lowest energy expenditure activity was 249 kcal per hour (for rescue from a small area), followed by 263 kcal per hour (for rescue from a vehicle). In these activities, large heavy machinery is used to secure conductors, destroy the entrance, unlock it, etc. [
19], so it is thought that energy expenditure has become low. In addition, it is conceivable that the range of activities, such as narrow areas and vehicles, was limited. The standard activity suit weighed 25 kg [
15], and it is thought that the activity was relatively low in load with relatively little addition of equipment, such as oxygen cylinders outdoors. From these facts, it is thought that energy expenditure has also become relatively low.
Additionally, the highest energy expenditure activity is a rescue operation from a high place with stair lifts and descents, which is 419 kcal per hour. The next highest was tunnel collapse rescue. In the case of a tunnel collapse accident, when entering the tunnel, an air respirator is attached, so the load is considered accordingly. In both cases, the load, activity, and range of action at the time of equipment and rescue of people in need of rescue were vast, so physical activity is thought to have increased, so it is thought that energy expenditure also increased. It has been shown that the load of equipment, such as an air respirator, imposes a biological load on fire fighters [
20]. Since there is a large difference in energy expenditure for each type of activity in large-scale disaster relief operations, it is thought that it will be possible to more easily estimate the total daily energy expenditure in combination with the expected activity implementation time by showing the energy expenditure of each activity as a standard value.
The total energy expenditure of fire fighters during normal duty was 3626 kcal per day in a survey of fire fighters [
21], wild and firefighter. It has been reported as 4878 kcal per day in a survey [
22] and 4009 kcal per day in urban fire fighters [
23]. AC Law reported 4716 kcal per day for wild fire fighters [
24] and 2531 kcal per day for urban fire fighters [
23]. In this study, the total energy expenditure was estimated to mean 4838 (±508) kcal. In previous studies, the DLW method, which is considered as the gold standard, required a long-term investigation; therefore, it was not possible to estimate energy consumption during the activities alone. Additionally, there are no studies investigating large-scale disasters with prolonged periods of time and multiple activities using the DLW method [
21,
22,
23]. In the case of the AC method, it is possible to measure only the activity time. The TEE of firefighters during a large-scale disaster under the AC Act was reported to be 3619 ± 499 kcal, but an underestimation was also reported [
15]. In this study, the AC and HR methods were combined to estimate energy consumption only during the active hours. As a result, authors believe they were able to evaluate the part that was considered to have been underestimated by the AC method. However, by the addition of the HR method an effect on changes in heart rate related to tension and temperature changes may be seen. This aspect needs to be considered in future studies.
When analyzing activity details, such as MET values and activity time for each activity type by activity group, group 3.4 has the highest energy expenditure, and stair climbing and descending has the least activity time. TEE was found to be the lowest. This is thought to be because the squadrons that performed energy-consuming activities because of the training are adjusting their activity time and subsequent activities. In the training subject to this survey, the elevation to the upper floors only occurred once, but, in the actual disaster, it is possible that it may occur multiple times, and the activity time may be longer, so the TEE is also considered to be higher. It has been shown that the longer the time spent wearing firefighting equipment, the greater the heat stress and the greater the load on the organism than the activity in a jersey [
25].
As an example, we calculated the TEE of an actual activity in a real disaster situation. During this disaster, a landslide occurred due to heavy rains, and people went missing on 3 July 2021 at Atami city in Shizuoka prefecture, Japan. This is a record of the rescue activities of second day after the disaster occurred (4 July 2021). In this rescue activity, firefighters carried out excavation activities to search for the missing people. Additionally, the TEE was estimated using data presented in (excavation activity) and the other activities (for example, eating, moving, meeting, etc.), referring to the METs table [
6]. We estimated a TEE of around 5436 kcal on 4 July 2021 (the second day of the disaster). By utilizing the results of this study and estimating the energy consumption of even more activities, it is expected that it will lead to an understanding of the energy expenditure of firefighters. Until now, the energy expenditure for each large-scale disaster activity has not been clarified. From the present research, it is expected to be able to estimate the energy expenditure for each type of disaster based on the activity records so far. In addition, according to the estimated energy expenditure, authors propose utilizing it for managing the amount of energy in the food to be replenished and for activity management, such as rotation of the crew members.
The activity training investigated in this study comprises the widest range of training currently measurable and is the longest running exercise currently conducted in Japan. This is also the subject of a survey, which includes a wide variety of activities. However, it is to be noted that additional investigation is necessary for activities that were not carried out in this survey target training (e.g., mountain rescue and water rescue). This study shows the importance of measurement in actual disaster activities, but it was difficult because they were not allowed to wear other equipment, such as Douglas bags, during the activity training. In order to confirm this result, it is necessary to do additional experiments in future studies using a Douglas bag and other methods. In this research, we focused on actually measuring the activities during disaster-relief operations, which are complex activities. We selected the longest running activity and targeted the maximum number of people who could be measured wearing accelerometers and heart rate monitors. However, this number of the participants is limited, and we believe that further research is needed. In addition, wearable sensors wearable sensors are less likely to interfere with training and work, and the data are easy to measure and record, so the number of examples can be increased in practical situations of fire-fighting and trainings. We did not consider the role of fatigue in this study. Since the time required varies greatly depending on the activity, it might be possible that fatigue has an effect. Moreover, the relationship between time and estimated energy expenditure per hour is not clear. Additionally, it is not known whether energy expenditure varies due to fatigue. This aspect also needs to be checked in future research. In addition, since disaster response activities were carried out throughout the day and night, it is necessary to consider the circadian rhythm in addition to the changes in heart rate and metabolism in the future.
Survey respondents were randomly selected from the members active in the target training, but since women were not included in the participating personnel, only men were included. This may be due to the fact that there are few female members in the Emergency Fire Rescue Team currently operating in Japan, but women are gradually being registered as members, and it is conceivable that women will also be dispatched to disaster activities. For these reasons, it is necessary to conduct surveys targeting women in the future. In addition, it is possible that the activity time is adjusted because the activity content is controlled because it is an activity drill, and the activity time is adjusted due to the fact that the squad that carried out high-intensity activities longer than the actual disaster. In addition, since activity records are self-reported, there may be differences from the actual situation. The results of this study can be applied to estimate the energy expenditure in not only for the firefighters, but also for individuals (e.g., Japan Self Defense Force, Police) involved in different types of disaster relief operations.
