  • 1. 産業技術総合研究所 ⾼高野了了成 2015年年6⽉月29⽇日 A  Look  Inside  Googleʼ’s  Data   Center  Networks ネタ元：Amin Vahdat, ”A Look Inside Google’s Data Center Network”, 2015 Open Network Summit Keynote. http://www.theplatform.net/2015/06/19/inside-a-decade- of-google-homegrown-datacenter-networks/
  • 2. Googleʼ’s  warehouse-‐‑‒scale   networking  infrastructure 2 •  B4  [SIGCOMM  2013] •  Andromeda  [ONS  2014] •  Firehose  -‐‑‒>  Watchtower  -‐‑‒>  Saturn  -‐‑‒>  Jupiter   [ONS  2015,  SIGCOMM  2015]
  • 3. B4:  Globally-‐‑‒deployed  SDN  WAN 3 Google Confidential and Proprietary Google's OpenFlow WAN Google Confidential and Proprietary G-Scale Network Hardware ● Built from merchant silicon ○ 100s of ports of nonblocking 10GE ● OpenFlow support ● Open source routing stacks for BGP, ISIS ● Does not have all features ○ No support for AppleTalk... ● Multiple chassis per site ○ Fault tolerance ○ Scale to multiple Tbps ⽬目的：リンク増設の削減、⾼高価な ネットワーク機器からの脱却 結果：リンク帯域使⽤用率率率30%→   70%を独⾃自スイッチで実現 OpenFlow@Google,  2012  Open  Network  Summit
  • 4. B4:  Globally-‐‑‒deployed  SDN  WAN •  設計⽅方針 –  アプリケーションはネットワーク帯域の使⽤用を事前 予約 –  アプリケーションの優先度度と使⽤用帯域をもとに中央 集権的に経路路計算し、スイッチに経路路注⼊入 •  所感 –  光パスとの相性はよい –  OpenFlowの代わりにOGF  NSI標準を利利⽤用すること も可能では 4
  • 5. Andromeda  network  virtualization •  Goal:  the  raw  performance  of  the  underlying   network  while  simultaneously  exposing  NFV 5 http://googlecloudplatform.blogspot.jp/2014/04/enter-andromeda- zone-google-cloud-platforms-latest-networking-stack.html
  • 6. Traffic  generated  by  servers  in   Google  DCs 6
  • 7. Motivation •  Traditional  network  architectures  could  not   keep  up  with  bandwidth  demands  in  the  DC •  Operational  complexity  of  “box-‐‑‒centric”   deployment •  Inspired  by  server  and  storage  scale  out,   employed  three  principles  to  redesign  DCN –  Clos  Technologies –  Merchant  Silicon –  Centralized  Control 7 Amdahlʼ’s  lesser  known  law  (late  1960ʼ’s):   1Mbit/sec  of  IO  for  every  1Mhz  of   computation  in  parallel  computing 1  server  (64*2.5  Ghz)  :  100  Gb/sec 50k  servers  :  5  Pb/sec!!
  • 8. Google  DCN  Over  Time 8 Datacenter generation Year Merchant Silicon ToR configuration Aggregation block Spine block Fabric speed Host speed Aggregate bandwidth Four-Post CRs 2004 48x1G - - 10G 1G 2Tb/sec Firehose 1.0 2005 8x10G, 4x10G 2x10G up, 24x1G down 2x32x10G 32x10G 10G 1G 10Tb/sec Firehost 1.1 2006 8x10G 4x10G up, 48x1G down 64x10G 32x10G 10G 1G 10Tb/sec Watchtower 2008 16x10G 4x10G up, 48x1G down 4x128x10G 128x10G 10G 1G 82Tb/sec Saturn 2009 24x10G 24x10G 4x288x10G 288x10G 10G 10G 207Tb/sec Jupiter 2012 16x40G 16x40G 8x128x40G 128x40G 10G/40G 10G/40G 1.3Pb/sec (- 2004) (2005 -)
  • 9. 9 Datacenter generation Year Merchant Silicon ToR configuration Aggregation block Spine block Fabric speed Host speed Aggregate bandwidth Firehose 1.0 2005 8x10G, 4x10G 2x10G up, 24x1G down 2x32x10G 32x10G 10G 1G 10Tb/sec Firehost 1.1 2006 8x10G 4x10G up, 48x1G down 64x10G 32x10G 10G 1G 10Tb/sec
  • 10. 10 Datacenter generation Year Merchant Silicon ToR configuration Aggregation block Spine block Fabric speed Host speed Aggregate bandwidth Watchtower 2008 16x10G 4x10G up, 48x1G down 4x128x10G 128x10G 10G 1G 82Tb/sec (four  edge  aggr.  switches)
  • 11. 11 Datacenter generation Year Merchant Silicon ToR configuration Aggregation block Spine block Fabric speed Host speed Aggregate bandwidth Saturn 2009 24x10G 24x10G 4x288x10G 288x10G 10G 10G 207Tb/sec
  • 12. 12 Datacenter generation Year Merchant Silicon ToR configuration Aggregation block Spine block Fabric speed Host speed Aggregate bandwidth Jupiter 2012 16x40G 16x40G 8x128x40G 128x40G 10G/40G 10G/40G 1.3Pb/sec
  • 13. Jupiter  Superstack 13
  • 14. 【参考】Facebook  6-‐‑‒pack  open   hardware  modular  switch 14 •  40Gbps  x  64  ports •  Dual-‐‑‒stage  clos  network •  Linux-‐‑‒based  Operating  System   (FBOSS)
  • 15. 25/50  Gigabit  Ethernet •  25  Gigabit  Ethernet  Consortium –  Arista,  Broadcom,  Google,  Mellanox,  Microsoft –  http://25gethernet.org/ •  2550100  Alliance –  http://www.2550100.com/ 15

×
