Deep Dive: AWS Command Line Interface

2. Crash Course Intro to the AWS CLI FOUNDATION ADVANCED SCENARIOS Exploring Key Functionality Looking at Advanced CLI Features

3. Crash Course Intro to the AWS CLI

4. AWS Command Line Interface Unified tool to manage your AWS services

5. MSI (Windows) Bundled (cross platform) pip (cross platform)

6. aws configure

7. $ aws ec2 describe-instances Service (command) Operation (subcommand)

8. $ aws iam list-access-keys Service (command) Operation (subcommand)

9. { "Places": [ { "City": "Seattle", "State": "WA" }, { "City": ”Las Vegas", "State": "NV" } ] } --output JSON

10. PLACES Seattle WA PLACES Las Vegas NV --output text

11. -------------------------- | SomeOperationName | +------------------------+ || Places || |+------------+---------+| || City | State || |+------------+---------+| || Seattle | WA || || Las Vegas | NV || |+------------+---------+| --output table

12. All Outputs • JSON Text PLACES Seattle WA PLACES Las Vegas NV Table -------------------------- | SomeOperationName | +------------------------+ || Places || |+------------+---------+| || City | State || |+------------+---------+| || Seattle | WA || || Las Vegas | NV || |+------------+---------+| { "Places": [ { "City": "Seattle", "State": "WA" }, { "City": ”Las Vegas", "State": "NV" } ] }

13. Demo Basic AWS CLI Usage

14. Foundation Exploring Key Functionality

15. Configuration

16. aws configure

17. aws configure AWS access key ID [**ABCD]: AWS secret access key [****************EFGH]: Default region name [us-west-2]: Default output format [None]:

18. aws configure <subcommand>

19. aws configure <subcommand> list - list common configuration sources get - get the value of a single config var set - set the value of a single config var

20. aws configure get region

21. aws configure set profile.prod.region us-west-2

22. A profile is a group of configuration values

23. aws configure --profile prod

24. Configuration Files ~/.aws/credentials ~/.aws/config • Supported by all AWS SDKs • Only contains credentials • Used only by the CLI • Can contain credentials (but not the default behavior)

25. ~/.aws/credentials ~/.aws/config

26. aws configure set profile.prod.aws_access_key_id foo ~/.aws/credentials ~/.aws/config

27. aws configure set profile.prod.aws_access_key_id foo ~/.aws/credentials ~/.aws/config [prod] aws_access_key_id = foo

28. aws configure set profile.prod.aws_secret_access_key bar ~/.aws/credentials ~/.aws/config [prod] aws_access_key_id = foo

29. aws configure set profile.prod.aws_secret_access_key bar ~/.aws/credentials ~/.aws/config [prod] aws_access_key_id = foo aws_secret_access_key = bar

30. aws configure set profile.prod.region uswest2 ~/.aws/credentials ~/.aws/config [prod] aws_access_key_id = foo aws_secret_access_key = bar

31. aws configure set profile.prod.region uswest2 ~/.aws/credentials ~/.aws/config [prod] aws_access_key_id = foo aws_secret_access_key = bar [profile prod] region = us-west-2

32. aws configure set profile.prod.output text ~/.aws/credentials ~/.aws/config [prod] aws_access_key_id = foo aws_secret_access_key = bar [profile prod] region = us-west-2

33. aws configure set profile.prod.output text ~/.aws/credentials ~/.aws/config [prod] aws_access_key_id = foo aws_secret_access_key = bar [profile prod] region = us-west-2 output = text

34. create-new-user.sh

40. Use the aws configure suite of subcommands

41. Query

42. Implementation Details --query Processing

46. Implementation Details --query Processing --query User[0].[UserName,Path,UserId]

47. Implementation Details --query Processing --query User[0].[UserName,Path,UserId]

50. http://jmespath.org A Query Language for JSON

51. Demo JMESPATH

52. http://jmespath.org A Query Language for JSON

53. Waiters

54. Amazon EC2 Instance State Transitions

55. ec2-instance-running.sh #!/bin/bash instance_id=$(aws ec2 run-instances –image-id ami-12345 --query Reservations[].Instances[].InstanceId --output text) instance_state=$(aws ec2 describe-instances –instance-ids $instance_id --query 'Reservations[].Instances[].State.Name') while [ "$instance_state" != "running" ] do sleep 1 instance_state=$(aws ec2 describe-instances –instance-ids $instance_id --query 'Reservations[].Instances[].State.Name') done

61. ec2-waiters.sh instance_id=$(aws ec2 run-instances –image-id ami-12345 --query Reservations[].Instances[].InstanceId --output text) aws ec2 wait instance-running –instance-ids $instance_id

62. ec2-waiters.sh instance_id=$(aws ec2 run-instances –image-id ami-12345 --query Reservations[].Instances[].InstanceId --output text) aws ec2 wait instance-running –instance-ids $instance_id subcommand Describe-instances options waiter name

63. Advanced Scenarios Looking at advanced AWS CLI features

64. Templates

65. The AWS CLI is data driven

66. Implementation Details JSON Models

69. aws ec2 run‐instances –cli-input-json file://arguments.json

70. What else can we do?

71. aws ec2 run‐instances –generate-cli-skeleton

72. Demo Creating and using JSON templates

73. Credential Providers

79. Delegate access to AWS resources using AWS Identity and Access Management (IAM) roles

80. IAM Roles Production Development

81. IAM Roles Production Development

82. v IAM Roles Production Development Role Policy Trust Policy role

83. IAM Roles Production Development AssumeRole AWS Security Token Service role

84. IAM Roles Production Development AssumeRole AWS Security Token Service role token

85. IAM Roles Production Development AssumeRole AWS Security Token Service role token

86. aws configure set profile.prodrole.source_profile dev aws configure set profile.prodrole.role_arn arn:aws:iam… configure-role.sh

87. ~/.aws/credentials ~/.aws/config [profile prodrole] role_arn = arn:aws:iam source_profile = dev

88. ~/.aws/credentials ~/.aws/config [profile prodrole] role_arn = arn:aws:iam source_profile = dev

89. Demo Using roles with the AWS CLI

90. Amazon S3 Streaming

91. aws s3 cp

92. We want to avoid disk

93. aws s3 cp – s3://bucket/key

94. aws s3 cp s3://bucket/key -

95. Compress

96. aws s3 cp s3://bucket/key ‐ | bzip2 -best | aws s3 cp - s3://bucket/key.bz2

97. Summary

98. Wrapping Up • Configuration • Waiters • Query • Templates • Credential Providers • Amazon S3 Streaming

99. For More Information • https://github.com/aws/aws-cli • http://docs.aws.amazon.com/cli/latest/userguide/ • https://forums.aws.amazon.com/forum.jspa?forumID=150 • http://docs.aws.amazon.com/cli/latest/reference/ • http://jmespath.org/

100. Thank you! tpjones@amazon.com
